POD - SERIES

POD Series Ozone Destruct Unit

A compact catalytic device, designed for venting off-gas from contact vessels - effectively converts ozone to environmentally safe oxygen

Benefits

  • Economical and reliable method of eliminating ozone in off-gas to acceptable levels prior to discharge into the atmosphere
  • Positive pressure design for venting off-gas from contact vessels
  • Low energy heater maintains the saturated off-gas above its dew point protecting the metal oxide catalyst
  • Applications

  • Ozone contact vessels
  • Adapts easily to a wide range of systems
  • Features

  • Constructed of 304 stainless steel
  • Simplicity of design facilitates ease of use
  • Weather tight and built for outdoor installation
  • Low temperature operation
  • Low pressure drop-maximum of 0.5 psig
  • Specifications

    Model
    Number
    Flow
    SCFM
    Inlet
    Inches
    Watts Diameter
    Inches
    Height
    Inches
    Wt
    lbs
    POD-3 3 3/4 25 4 11 2.5
    POD-10 10 1 50 6 11 8
    POD-30 30 2 150 10 14 26
    POD-50 50 3 250 12 17 43

    Specifications for larger destruct units available upon request.

    Note: The catalyst should not be exposed to excessive moisture, oil, foam or organic loading. This may result in reduced catalyst performance.

    Ozone catalytic destruct devices operate on 120V, 60Hz, 1 phase.

    Options and Accessories

    We offer a complete line of accessories, components and test kits to augment and/or complete your ozone installation including:
    • Test kits
    • Diffusers/eductors a Level control
    • Contact vessels
    • Air compressors
    • ORP monitor
    • Auto control (PN series only)
    • Ambient ozone monitor
    • Dissolved ozone monitor

    Download POD-50 Gen Arr PDF

    Download POD Installation PDF
